Name: EUR PET Veterinary Instrument Portable Radiography System Digital Medical Radiography System X Ray Machine
Brand: ShoppingTogether
Price: 8999.0 PHP
Availability: InStock

EUR PET Veterinary Instrument Portable Radiography System Digital Medical Radiography System X Ray Machine
Technical Advantage
High resolution and high sensitivity X - ray flat panel detector	1. High resolution wireless flat panel detector ensures excellentimage quality and reliable clinical diagnosis. 2. Fast imaging time, high efficiency, direct image formation ona computer, free of film processing. 3. Lightweight design, IP56 protection level.
lmported intelligent high voltage X-ray generator	1. Low input current design, 220V conventional voltage withoutsupply transformation. 2. Originally Toshiba imported tube with lower radiation and highersafety and health factor
Simple operation and clear image	1. A new generation flat panel of iRay Venu1717X specially tailoredfor pet DR. 2. Open APR integration with kV, mA and mAs control and exposureconditions per body thickness. 3. Special veterinary radiography mode, easy to operate and safe to use. 4. Pet information and image management is completed with onekey by simple operation. 5. DICOM 3.0 interface supports image flipping, panning, croppingannotation processing, and work list output.
Optimized and humanized design	1. Multiple self-protection and fault alarm function, safe and reliable 2. Automatically save parameters in case of sudden power failurewithout loss of data. 3. Four-way floating table with electromagnetic brake to ensureaccurate positioning. 4. Applicable to standard sockets without mains voltage conversion. 5. Rotary visor is equipped with LED lighting/timer and can alsobe operated by foot switch or foot brake. 6. Restraint straps are designed to allow the radiologist to leavethe control area during filming
Unique clinical experience	1. High quality X-ray single block ensures more details and less dose 2. Medical fiberboard countertops to prevent scratches.
Remote contactless service(optional)	Remote debugging and control, rapid maintenance, repair, and upgrade.

Disassemble the packing box of the X-ray tube and the beam limiter, and take
out the X-ray tube and the fixing disc of the beam limiter, as shown in Figure

one person will place the X-ray tube on the fixing bracket, and support the X-ray tube to prevent it fromslipping.Theother person connects the beam limiter retaining disc to the X-ray tube with a hex socket screw. Note that the arrow in Figure 2 indicates that the notch is towards the operator.

Place the X-ray tube in place along the black marked line indicated by the arrow in
Figure 3 and tighten the hex screw again.

Refer to Figure to install the beam limiter on the beam limiter retaining disc and pre-tighten the 4 outer hex bolts to prevent slipping. After completing step confirm that the beam limiter cross cursor is confirmed to be in line with the detector cross mark, and then tighten the 4 outer hex bolts and 1 inner hex setting screw.

rotate the anode line of the X-ray tube and the power
line of the beam limiter, and insert them in accordance with the direction and
color

place the flat panel detector in the outgoing direction indicated by the vertical arrow, turn the nylon pressure plate shown in the red
circle and tighten the screw. Insert the flat panel detector into the bed frame at the position indicated by the inclined arrow.

Q1: What is the advantage about your company? A: We are professional exporter of veterinary equipment and pet grooming products with 15 years' rich experience. We can give your suitable suggestions and solutions. Q2:Is there a discount? A: Different quantity has different discount. Q3: How to confirm the Product Quality before placing orders? A: You can buy 1 pc sample firstly. Or you can send us your detailed specifications and requests, we will customzied the products according to your requests. Q4: How do you treat quality complaint? A: First of all, our quality control will reduce the quality problem to near zero. If there is a real quality problem caused by us, we will send you free accessories for replacement or refund your loss on the basis of providing the video or photos; If any damage caused by shipping forwarder, please help to take video or photo at the first time at the port before you accept it. We will talk to forwarder directly to solved it. Q5: What is your warranty? A: Most of our products warranty are 1 year or 2 years for free, and a life-long maintenance. Q6: How about delivery leadtime? A: Delivery lead time: Usually about 7-25 working days after payment confirmed. Q7: How to start orders or make payments? A: Proforma invoice will be sent firstly after confirming your order, it will enclosed our bank information. Payment by T/T, credit card, Western Union or Paypal, etc. Q8: How to contact us ? A: You can chat with us by Trademanager, Online messages, etc.You can choose your interested products and send an inquiry, dial our telephone directly, or send an email to us directly, you will get our reply within 8 hours.
